A step-by-step installation guide by R&B Instrument Inc. Learn how to correctly position, support, and calibrate your RBCM Coriolis meter while overcoming common challenges like vibration and environmental stress.

Q1: Does the RBCM Coriolis meter require straight pipe runs for installation?
A: Unlike ultrasonic or turbine technologies, the RBCM series by R&B Instrument Inc. does not strictly require minimum straight rigid pipe upstream or downstream. However, we recommend a short straight run at the inlet and outlet whenever possible to ensure maximum measurement stability.

Q2: How should I address vibration issues at the installation site?
A: Vibrations can interfere with the meter's oscillating tubes. R&B Instrument Inc. suggests installing the meter away from high-vibration equipment or using anti-vibration mounts. For pump-induced pulsations, the use of dampeners is highly effective.
Q3: What is the importance of support structures for the RBCM meter?
A: Proper support is crucial. R&B Instrument Inc. advises installing rigid structures before mounting to prevent mechanical stress on the meter body and connections, which could otherwise lead to measurement errors, leakages, or structural damage.
Q4: How can I protect the RBCM electronics from extreme environments?
A: Extreme temperature or humidity can impact electronic reliability. R&B Instrument Inc. recommends selecting a location with stable conditions or installing protective enclosures and shelters to shield the meter from environmental extremes.
Q5: What are the final steps after the physical installation is complete?
A: Once secured, R&B Instrument Inc. requires making electrical and data connections in accordance with local codes. Finally, perform calibration and comprehensive testing to verify that the meter is operating accurately within your specific process parameters.
